Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > Fax (626) 855-4862
Model Number & Options______________________________________________Quantity___________
Company_________________________________________________________Date_______________
Contact_____________________________________Title_____________________________________
Approval for Manufacturing/Signature_____________________________________________________
SELECTION SUMMARY & APPROVAL FOR MANUFACTURING
Model Number & Options______________________________________________Quantity___________
Company_________________________________________________________Date_______________
Contact_____________________________________Title_____________________________________
Approval for Manufacturing/Signature_____________________________________________________
SELECTION SUMMARY & APPROVAL FOR MANUFACTURING
Whitehall Mfg. > P.O. Box 3527 > City of Industry, CA 91744 > (800) 782-7706 > (626) 968-6681 > Fax (626) 855-4862
All dimensions are nominal and subject to
manufacturer's change without notice. Whitehall
assumes no responsibility fo use of void or
suspended data
© Whitehall Manufacturing,
Member of Morris Group International.
Please visit www.whitehallmfg.com for most
current specifications.
Last Update: 12/06/13
® Care-Ware Bedside Patient
Care Units
MODEL NUMBER AND OPTIONS SELECTION
BASE MODEL NUMBER (Must Specify)
4044 Versalette™ - 47" Wide With Rectangular Lavy
TOILET ORIENTATION (Must Specify)
Left Hand Toilet
Right Hand Toilet
NOTES: L (Left) or R (Right) indicates toilet location
in opened position when facing th fixture.
Lavy is always located on side opposite the toilet.
BACKSPLASH ORIENTATION (Must Specify)
Back Wall Only (One Wall)
Right Hand Corner (Two Wall)
Left Hand Corner (Two Wall)
Alcove (Three Wall)
FLUSH VALVE SELECTION
- 1.28 GPF
- 1.6 GPF
GPF
COLOR SELECTION (Must Specify)
Countertop ____________ Cabinet ____________
q
TOILET MOUNTING AND WASTE (Must Specify)
q -OFFW Off-Floor, Wall Outlet
q -ONFF On-Floor, Floor Outlet
q -ONFW On-Floor, Wall Outlet
q -L
q -R
q -1
q -2
q -3
q -4
q -HET
q -ULF
q -3.5
PRODUCT OPTIONS (Must Specify)
Aerator (on Gooseneck Spout)
Battery Operated (-SO)
Bedpan Lugs
Bedpan Washer Drain
Corterra™ Solid Surface Countertop
w/ Integral Lavy,
Corterra™ Solid Surface Countertop
Specify Color: ____________
® Corian Countertop w/ Stn. Steel Lavy
® Corian Countertop w/ Integral
Contrasting Colored Lavy Bowl
Stainless Steel Countertop
Hemo-Dialysis Box, Single Valve
Hemo-Dialysis Box, Dual Valve
Extended Countertop
Specify Length: ____________
Enviro-Glaze:
Lavy
Toilet Exterior Only
Toilet Interior & Exterior
Specify Color: ____________
Less Countertop, Furnish Lavy & Valve
Less Countertop & Lavy, Furnish Valve
Less Countertop, Lavy & Valve
Laminar Flow Nozzle
Less Lavy & Valve, Furnish Countertop
Lavatory Hose Spray
Less Valve, Furnish Countertop & Lavy
Metal Template
Optional Color Plastic Panels
Specify Color: ____________
Special Finish Specify Color: ___________
Sensor Operated Valve
Swing Up Grab Bar
Concealed H & C Foot Pedal Operated
Air-Control Valve
q -AE
q -BAT-SO
q -BL
q -BWD
q -CCL
Specify Color: _________
q AMA Anti-Microbial Additive
q -CCT
q AMA Anti-Microbial Additive
q -CNCT
q -CNCTL
q -CS
q -DB1
q -DB2
q -EC
q -EG
q
q
q
q -LCT
q -LCTL
q -LCTLV
q -LFN
q -LLV
q -LS
q -LV
q -MT
q -OCP
q -OCR Optional Color Resin Countertop
Specify Color: ____________
q AMA Anti-Microbial Additive
q -SF
q -SO
q -SUG
q -VF
4044
1.
2.
6.
5.
3.
NOTES:
7.
4. Stainless Steel Toilet
Stainless Steel Lavatory
Flush Valve Pushbutton
Lavatory Gooseneck Faucet Bedpan Washer Compartment
Pivoting Padded Toilet Cover
Storage Compartment
MODEL# 4044-L-2
9"
(229)
27"
(686)
18
1
2
"
(470)
47"
(1194)
MODEL# 4044-L-1
7
6" Min.
(152)
9"
(229)
27"
(686)
18
1
2
"
(470)
47"
(1194)
18"
(457)
36"
(914)
3"
(76)
6
4
5
2
1
3
46" Cabinet
(1168)
