Warner Electric MCS-131 - Manual (Page 8)

DC
COM +24V +4.8V
AC
INPUT
EARTH
GND
DC
COM +12V CH2
LED
CH1 P.E. STOP
CH 2 CH 1
INH START
OPTIONAL LOGIC BOARD 6090-448-016
MCS-131
120 V
OR
240V
AC
120 V
OR
240V
AC
MCS-638
S3
S3
S2
S2
S1
S1
SWITCHING
S1 - START INPUT SWITCH
S2 - PHOTOELECTRIC INHIBIT SWITCH
S3 - STOP INPUT SWITCH
NOTE: INPUT SWITCHING DEPENDENT ON
SWITCH SETTINGS ON LOGIC BOARD, PART NUMBER 6040-448-016
SWITCHING
S1 - START INPUT SWITCH
S2 - PHOTOELECTRIC INHIBIT SWITCH
S3 - STOP INPUT SWITCH
NOTE: INPUT SWITCHING DEPENDENT ON
SWITCH SETTINGS ON LOGIC BOARD, PART NUMBER 6040-448-016
TERMINAL DESIGNATIONS + + _ _
1. START INPUT
2 PHOTOELECTRIC INHIBIT
3
4
5
6
7 STOP INPUT
8 PHOTOELECTRIC INPUT
9 LED CHANNEL 1
10 LED CHANNEL 2
11 +12 VDC OUTPUT
12 DC COMMON
13 EARTH GROUND
14
15
16 +4.8 VDC OUTPUT (Optional Board)
17 DC COMMON
18 +24 VDC OUTPUT
1. START INPUT
2 PHOTOELECTRIC INHIBIT
3
4
5
6
7 STOP INPUT
8 PHOTOELECTRIC INPUT
9 LED CHANNEL 1
10 LED CHANNEL 2
11 +12 VDC OUTPUT
12 DC COMMON
13 EARTH GROUND
14
15
16 +4.8 VDC OUTPUT (Optional Board)
17 DC COMMON
18 +24 VDC OUTPUT
CHANNEL 1 OUTPUT
CHANNEL 1 OUTPUT
CHANNEL 2 OUTPUT
CHANNEL 2 OUTPUT
AC INPUT
AC INPUT
+
+
+
+
_
_
_
_
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
TERMINAL DESIGNATIONS
+24V
DC
COM +4.8V
POWER SUPPL
Y
6040-448-016
AC
INPUT
EARTH
GND
DC
COM +12V
LED
CH2 CH1 P.E. STOP
CH2 CH1
INH START + + _ _
OPTIONAL LOGIC BOARD 6040-448-016
MCS-131
MCS-624
18 17 16 15 14 13 12 11 10 8 7 9 6 5 4 3 2 1
Figure 3 - Expanded Input Switching with Logic Board, 6090-448-016 and MCS-638
Color Mark Scanner
Figure 4 - Expanded Input Switching with Logic Board 6040-448-016 and MCS-624 Mark Reader
Warner Electric • 800-825-9050 P-262 • 819-0493 7
