3
Specification
SPECIFICATION
S-62-FF S-62-AA S-62-FA
Capacity 2000 lbs. 2000 lbs. 2000 lbs.
Fork Lift Height 62" 62" 62"
Fork Dimension 42x5.9x2 3/8" 42x4x1-1/4"" 42x5.9x2 3/8"
Overall fork width 26-3/4" 26-3/4" 26-3/4"
Ground Clearance 1" 1" 1"
Lowered Fork H. 3-3/8" 2-1/8" 2-9/16"
H. Overall Extended 81-7/8" 81-7/8" 81-7/8"
Head Dimension 26-1/2x30x29-3/4" 26-1/2x30x29-3/4" 26-1/2x30x29-3/4"
Loading Center 23-5/8" 23-5/8" 23-5/8"
Wheel Base 44-3/4" 44-3/4" 44-3/4"
Turning Radius 55" 55" 55"
Support Wheel Φ 4x2" Φ 4x2" Φ 4x2"
Front Wheel Φ 3-1/8x3-3/8" Φ 3-1/8x3-3/8" Φ 3-1/8x3-3/8"
Drive Wheel Φ 10x3-1/8" Φ 10x3-1/8" Φ 10x3-1/8"
Overall Size 68x30x82 69x46x82 68x46x82
Lift Load 2.95"/s 2.95"/s 2.95"/s
Speed Unload 5.9"/s 5.9"/s 5.9"/s
Load 4"/s 4"/s 4"/s
Lower
Speed
Unload 2"/s 2"/s 2"/s
Load 5km/h 5km/h 5km/h Travel
Speed
Unload 6km/h 6km/h 6km/h
Drive Motor 24V/700W 24V/700W 24V/700W
Lift Motor 24V/2.0KW 24V/2.0KW 24V/2.0KW
Controller 1207A-4102 1207A-4102 1207A-4102
Battery 2x12V/70Ah 2x12V/70Ah 2x12V/70Ah
Battery Charger DC 24V/6A Soneil DC 24V/6A Soneil DC 24V/6A Soneil
Weight 950 lbs. 990 lbs. 970 lbs.
Load Grade ability 6% 6% 6%
Unload Grade ability 10% 10% 10%
Width of Aisle 35-1/2" 52" 52"
Note: The load capacity is based on the situation when the center of the gravity is
located at the center of length of forks. When the center of gravity of goods is out
of the center of forks, the load capacity will be lessened compared to the center.
