Vestil SL-xxx-AA User Manual
Page 26
26
Electric circuit diagram and component list
NO
Name
Code
Specification
Qty
1
Power meter
MC
DC12V
1PC
2
Lift motor
M
DC12v/1.5KW
1PC
3
Battery
DP
12V/135Ah
1PC
4
Lift motor contactor
J
MZJ200S 12V
1PC
5
Control circuit fuse
FU1
FS-10
10A
1PC
6
Hydraulic circuit fuse
FU2
200A
1PC
7
Key switch
S1
JT-001
1PC
8
Emergency stop
S2
ZDK31-250
1PC
9
Lift limit switch
S3
TM1703
1PC
10
Lift micro switch
S4
YBLXW-5/11M
1PC
11
Diode
D1
IN5404
1PC
12
Diode
D2
IN4007
1PC
13
Battery charger
CDQ
12V/15A
1PC
