E LECTRIC / H YDRAULIC BOM – EM1-200 & -500, EHTT, EHTT-L
Item #: Qty.: Part number: Part description:
Electrical parts:
1 1 01-135-XXX Motor; varies by customer spec; contact factory
2 1 LC1-D1810-24V Motor contactor, 30A, w/ 24 VAC coil
3 1 01-129-001 Transformer, control; w/ 24 VAC secondary
4 1 AGC 2 Fuse, for control circuit
5 1 01-029-006 Control enclosure, 6”W x 6”L x 4”D (EM1-200)
1 01-029-007 Control enclosure, 6”W x 8”L x 4”D (EM1-500, EHTT, EHTT-L)
6 1 01-522-015 Pushbutton control on 8’ cord
7 1 or 2 99-034-008 Solenoid coil, 24 VAC (2 on EM1-500, EHTT, EHTT-L)
8 1 or 2 01-033-017 Connector cord, for solenoid (2 on EM1-500, EHTT, EHTT-L)
9 1 01-033-015 Cord, power, 14/3, 9’ long, w/ NEMA 5-15 plug (115V units)
10 1 or 2 01-022-001 Limit switch, roller-arm (N.C.) (2 on EM1-500, EHTT, -L)
11 1 159/D Multi-pole terminal strip
Hydraulic parts:
12 1 99-153-006 Valve, relief, 210 bar
13 1 99-153-015 Valve, solenoid, N.C. (EM1-200)
14 2 99-153-017 Valve, 2-pos, 3-way (EM1-500, EHTT, EHTT-L)
15 2 99-153-019 Valve, 3:1 counterbalance (EM1-500, EHTT, EHTT-L)
16 1 99-153-011 Valve, check
17 1 99-153-038 Flow control spool, 1 gpm (EM1-200)
18 1 or 2 99-021-XXX Cylinder, displacement; varies by model and size; contact factory
19 1 or 2 99-136-XXX Cylinder seal kit; contact factory
20 1 01-127-010B Manifold, single-acting (EM1-200)
1 99-127-016B Manifold, double-acting (EM1-500, EHTT, EHTT-L)
21 1 01-143-XXX Pump, hydraulic; varies by model; contact factory
22 1 01-123-008 Reservoir (EM1-200)
1 03-023-001 Reservoir (EM1-500, EHTT, EHTT-L)
23 1 DPS-40-N06 Breather plug
24 1 01-031-005 Fitting, intake screen (EM1-500, EHTT, EHTT-L)
25 3-5 HO 150 Hydraulic fluid (quarts)
