Vestil D series hoppers User Manual
Page 3
11/4/2013
D & H series hoppers, manual
Copyright 2013 Vestil Manufacturing Corp.
Page 3 of 13
Medium duty 4,000lb (1,818kg) maximum rated load models; fabricated from 10 gauge steel
D-25-MD
¼
(~0.19 m
3
)
20 x 41¼ x 27
7
/
8
~(50.8 x 104.8
x
70.8)cm
26 x 52 x 38
~(66 x 132.1 x 96.5)cm
18
(~45.7cm)
385
(~175kg)
D-33-MD
1
/
3
(~0.25 m
3
)
20 x 41¼ x 27
7
/
8
~(50.8 x 104.8
x
70.8)cm
26 x 52 x 38
~(66 x 132.1 x 96.5)cm
18
(~45.7cm)
390
(~177.3kg)
D-50-MD
½
(~0.38 m
3
)
30 x 41¼ x 27
7
/
8
~(76.2 x 104.8
x
70.8)cm
33¼ x 52 x 38
~(84.5 x 132.1 x 96.5)cm
18
(~45.7cm)
420
(~190.9kg)
D-75-MD
¾
(~0.57 m
3
)
28¼ x 54½ x 32½
~(71.8
x
138.4
x
82.6)cm
31½ x 60½ x 43
~(80 x 153.7 x 109.2)cm
18
(~45.7cm)
525
(~238.6kg)
D-100-MD
1
(~0.76 m
3
)
38 x 54¼ x 32½
~(96.5
x
138.4
x
82.6)cm
41¼ x 61 x 42
5
/
8
~(104.8 x 154.9 x108.3)cm
18
(~45.7cm)
625
(~284.1kg)
D-150-MD
1½
(~1.15 m
3
)
40 x 63¾ x 41½
~(71.8
x
138.4
x
82.6)cm
43¼ x 61 x 52
~(109.9 x 154.9 x 132.1)cm
28
(~71.1cm)
670
(~304.5kg)
D-200-MD
2
(~1.53 m
3
)
53 x 63¾ x 41½
~(134.6
x
162
x
105.4)cm
56¼ x 61 x 52
3
/
8
~(142.9 x 154.9 x 133)cm)
28
(~71.1cm)
730
(~331.8kg)
D-250-MD
2½
(~1.91 m
3
)
66¼ x 63¾ x 41½
~(168.3
x
162 x 105.4)cm
69½ x 69 x 52
~(176.5 x 175.3 x 132.1)cm
28
(~71.1cm)
795
(~361.4kg)
D-300-MD
3
(~2.29 m
3
)
78
3
/
16
x 63¾ x 41½
~(198.6
x
162
x
105.4)cm
81
7
/
16
x 61 x 50¾
~(206.9 x 154.9 x 128.9)cm
28
(~71.1cm)
991
(~450.5kg)
Heavy duty 6,000lb (2,727kg) maximum rated load models; fabricated from 8 gauge steel
D-25-HD
¼
(~0.19 m
3
)
20 x 41¼ x 27
7
/
8
~(50.8 x 104.8
x
70.8)cm
26 x 52 x 38
~(66 x 132.1 x 96.5)cm
18
(~45.7cm)
410
(~186.4kg)
D-33-HD
1
/
3
(~0.25 m
3
)
20 x 41¼ x 27
7
/
8
~(50.8 x 104.8
x
70.8)cm
26 x 52 x 38
~(66 x 132.1 x 96.5)cm
18
(~45.7cm)
420
(~190.9kg)
D-50-HD
½
(~0.38 m
3
)
30 x 41¼ x 27
7
/
8
~(76.2 x 104.8
x
70.8)cm
33¼ x 52 x 38
~(84.5 x 132.1 x 96.5)cm
18
(~45.7cm)
455
(~206.8kg)
D-75-HD
¾
(~0.57 m
3
)
28¼ x 54½ x 32½
~(71.8
x
138.4
x
82.6)cm
31½ x 60½ x 43
~(80 x 153.7 x 109.2)cm
18
(~45.7cm)
560
(~254.5kg)
D-100-HD
1
(~0.76 m
3
)
38 x 54¼ x 32½
~(96.5
x
138.4
x
82.6)cm
41¼ x 61 x 42
5
/
8
~(104.8 x 154.9 x108.3)cm
18
(~45.7cm)
620
(~281.8kg)
D-150-HD
1½
(~1.15 m
3
)
40 x 63¾ x 41½
~(71.8
x
138.4
x
82.6)cm
43¼ x 61 x 52
~(109.9 x 154.9 x 132.1)cm
28
(~71.1cm)
745
(~338.6kg)
D-200-HD
2
(~1.53 m
3
)
53 x 63¾ x 41½
~(134.6
x
162
x
105.4)cm
56¼ x 61 x 52
3
/
8
~(142.9 x 154.9 x 133)cm)
28
(~71.1cm)
778
(~353.6kg)
D-250-HD
2½
(~1.91 m
3
)
66¼ x 63¾ x 41½
~(168.3
x
162
x
105.4)cm
69½ x 69 x 52
~(176.5 x 175.3 x 132.1)cm
28
(~71.1cm)
890
(~404.5kg)
D-300-HD
3
(~2.29 m
3
)
78
3
/
16
x 63¾ x 41½
~(198.6
x
162
x
105.4)cm
81
7
/
16
x 61 x 50¾
~(206.9 x 154.9 x 128.9)cm
28
(~71.1cm)
991
(~450.5kg)
D-350-HD
3½
(~2.68 m
3
)
88¼ x 63¾ x 41½
~(224.2
x
162
x
105.4)cm
92 x 69 x 52
~(233.7 x 175.3 x 132.1)cm
28
(~71.1cm)
1,110
(~504.5kg)
Options
Model Description
Net Weight
H-DAMP-4
Hopper dumping speed regulator for 4,000lb (medium duty) models
30 lb. (13.6kg)
H-DAMP-6
Hopper dumping speed regulator for 6,000lb (heavy duty) models
40 lb. (18.2kg)
LEKP
“Leak proof” welded hopper
5 lb. (2.3kg)
D-DPLG-1
1in. drain plug option
2 lb. (0.9kg)
D-DPLG-2
2in. drain plug option
2 lb. (0.9kg)
H-DPLG-1
1in. drain plug option
2 lb. (0.9kg)
H-DPLG-2
2in. drain plug option
2 lb. (0.9kg)
LUG
4 welded lifting lugs (around perimeter of hopper mouth)
150 lb. (68.2kg)
