3.10 Enabling the Computer Interface
The Computer Interface Mode is used to transfer test records from the WRM’s Flash EEPROM
to a PV via the RS-232C port. To use this mode, first run the provided PC software and then
connect the PC to the RS-232C port on the WRM. Then follow the steps below to enable the
WRM’s computer interface:
a. Start from the “START-UP” menu:
Press the [2] key (SETUP).
b. The following screen will be displayed:
Press the [4] key (NEXT PAGE).
c. The following screen will be displayed:
Press the
[1]
key (COMPUTER CONTROL).
d. The following screen will be displayed, indicating that the WRM’s computer interface is
enabled:
Press the [STOP] key to disable the computer interface mode and return to the
“START-UP” menu.
COMPUTER ITF MODE
1. COMPUTER CONTROL
2. SET TIME
3. VOLTAGE REG. TEST
1. ENTER XFMR ID
2. REVIEW RECORD
3. RESTORE RECORD
4. NEXT PAGE
1. TEST XFMR 11/02/09
2. SETUP 12:33:01
3. USER DIAG
