WRM-10P AND WRM-40 USER’S MANUAL REV 3
20
3.4 Performing a Resistance Test
a. Start from the “START-UP” menu:
Press the
[1]
key (TEST XFMR).
b. The following screen will be displayed:
Press the [1] key (V1 & V2 TEST) if you would like to perform a V1 & V2 test.
Press the
[2]
key (V1 ONLY TEST) if you would like to perform a V1 test only.
Please see section 3.5 for information about performing special tests.
NOTE
The test current is 10 Amps for the WRM-10P and 40 Amps for the WRM-40.
c. The following menu will be displayed:
Press the
[2]
key (NO).
d. The following screen will be displayed:
1. YES
Press the [1] key (YES) if you wish to convert readings to standard temperature.
The following screen will be displayed:
LTC or VTG REG?
1. YES
2. NO
WINDING MATERIAL:
1. COPPER, Tk=234.5
2. ALUMINUM, Tk=225
3. MANUALLY ENTER Tk
CONVERT READINGS
TO STANDARD TEMP?
1. YES
2. NO
1. V1 & V2 TEST
2. V1 ONLY TEST
3. SPECIAL TEST V1,V2
4. SPECIAL TEST V1
1. TEST XFMR 11/02/09
2. SETUP 12:33:01
3. USER DIAG
