LTCA-10/LTCA-40 USER’S MANUAL

If the LTC cable is connected, then pressing the

[LTC RAISE]

key when cycling from

lower to higher taps or pressing the

[LTC LOWER]

key when cycling from higher to

lower taps will start capturing data.

The following screen will be displayed indicating that the test is in progress:

h. When the pre-defined test time has elapsed or the

[STOP]

key is pressed, the “PRINT

TEST RESULTS?” menu will be displayed:

1. YES

Press the

[1]

key (YES) to print the test results on the built-in thermal printer. The

following menu will be displayed:

1. NORMAL PLOT

Press the

[1]

key (NORMAL PLOT) to print a normal plot. The printer will

begin to print. A typical normal (full-scale) plot is shown in figure 11.0.
Continue to step i.

2. EXPANDED PLOT

To print an expanded plot, press the

[2]

key (EXPANDED PLOT).

Continue to step i.

2. NO

Press the

[2]

key (NO) to bypass the printing of the test results. Continue to step

i. The “PRINT AN EXPANSION PLOT” menu will be displayed:

PRINT AN EXPANSION
PLOT?
1. YES

2. NO

SELECT PLOT TYPE:
1. NORMAL PLOT

2. EXPANDED PLOT

PRINT TEST RESULTS?
1. YES

2. NO

RUNNING DYNAMIC
LTC TEST T = 15
R1 = 7.369 m

“STOP” KEY TO ABORT

* XFMR ENERGIZED! *
