EZCT-2000 VERSION 1.x SOFTWARE MANUAL

REV 1

If the CT Tester is connected to the PC via the RS-232C (serial) port, un-check the
“Use USB port” and select the correct COM: port from the “Port:” drop-down list.

c. Localization

Select the correct frequency from the “Frequency:” drop-down list (60 Hz or 50 Hz).

NOTE

The frequency selection is for test record reference only. The CT’s are
tested at the supplied line voltage and frequency.

Select the preferred date format from the “Date Format:” drop-down list.

d. Summary Page Display

In this section you can configure the order the tap information is displayed on the
summary page of a test record (see section 4.6). To change the order of a tap, click
on the tap and then click on either the up arrow or the down arrow to the right of
the list. The selected tap will be moved up or down on the list respectively. The tap
order information is stored with each test record.

e. Test Record Path

The default location where test records are stored on the PC hard drive is listed in
the “Test Record Path” section. You can change the default test record storage
location by clicking on the “Edit” button and then selecting a different folder.

f. Test Plan Path

The default location where test plans are stored on the PC hard drive is listed in the
“Test Plan Path” section. You can change the default test plan storage location by
clicking on the “Edit” button and then selecting a different folder.

3. Click on the “OK” button to apply all changes to the application settings. The settings

will be permanently stored for the current and any future sessions.
