REV 2 VCBA VERSION 10.xx SOFTWARE MANUAL
66
5.7 Transferring a Test Plan to a CB Analyzer
To transfer a test plan from the PC to a CB analyzer:
1. Make sure the VCBA software is running. Connect the CB analyzer to the PC via the RS-
232C port.
2. The CB analyzer should enter Computer Interface Mode. Please see section 3.2 for
details.
3. Click on the File menu and select Transfer Test Plan to Timer… The following window will
be displayed:
4. If the test plan you would like to transfer is not listed in the current directory, click on
the “Path” button at the top of the window and browse to the directory containing the
file. Once you have located the test plan file, click on the file name and then click on the
“OK” button. The following window will be displayed:
