5. The following screen will be displayed:
Press the [4] key (NEXT PAGE).
6. The following screen will be displayed:
Press the [2] key (COMPUTER ITF).
7. The following screen will be displayed:
The CB analyzer is now ready to communicate with the VCBA software.
If you experience any problems enabling the Computer Interface Mode:
1. Turn off both the PC and the CB analyzer.
2. Connect the CB analyzer to the PC via the RS-232C port.
3. Turn on the computer and run the VCBA software.
4. Follow steps 4-7 in the above section to put the CB analyzer in computer interface
mode.
COMPUTER ITF MODE
“STOP” TO ABORT
1. SHOT DESCRIPTION
2. COMPUTER ITF
3. SET CLOCK
4. SET PRINT MODE
1. ANALYSIS POINTS
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
