RJ1P23... RJ1P48... RJ1P60...
Operational voltage range 90 to 265VAC 200 to 550VAC 410 to 660VAC
Non-rep. peak voltage 650V
p
1200V
p
1200V
p
Operational frequency range 45 to 65Hz 45 to 65Hz 45 to 65Hz
Output power 0 to 99% 0 to 99% 0 to 99%
Power factor
≥
0.9 @ 230VACrms
≥
0.9 @ 480VACrms
≥
0.9 @ 600VACrms
Load status indication Red LED Red LED Red LED
Output power resolution
MODE 1 Phase Angle 1/300 @ 50Hz, 1/300 @ 60Hz
MODE 2 Full Cycle 1/64 @ 50Hz, 1/64 @ 60Hz
MODE 3 Burst with 1s period 1/50 @ 50Hz, 1/60 @ 60Hz
MODE 4 Burst with 3s period 1/150 @ 50Hz, 1/180 @ 60Hz
MODE 5 Burst with 10s period 1/500 @ 50Hz, 1/600 @ 60Hz
Approvals UL, cUL
CE-marking Yes
RJ1P..I...
Current controlled input
Control current range
4 - 20mA
Max. allowable input current 50mA
Pick up current 4.2mA
Drop out current 3.9mA
Control status indication Green LED
Reverse polarity protected Yes
Voltage drop 10VDC @ 20mA
RJ1P..V...
Voltage controlled input
Supply voltage range, Vss
20 - 28VAC/DC
Supply current 18mA @ 24VDC
23mA @ 24VAC
Control voltage range, Vcc 0 - 10VDC
Control input current 0.1mA @ 10VDC
Reverse polarity protected Yes
Pick up voltage 0.5VDC
Drop out voltage 0.05VDC
Control status indication Green LED
2 Specifications are subject to change without notice (27.06.2006)
RJ1P
Input Specifications
General Specifications
Weight Approx. 430 g
Housing material PBT Flame retardant
Control terminal cable size
Min 1 x 0.5 mm 2 (1 x AWG20)
Max 1 x 4.0 mm 2 (1 x AWG12) or
2 x 2.5 mm 2 (2 x AWG14)
Mounting torque max. 0.6 Nm Posidriv 0 bit
Control terminal screw M3
Power terminal cable size
Min 1 x 4 mm 2 (1 x AWG12)
Max 1 x 25 mm 2 (1 x AWG3) or
2 x 10 mm 2 (2 x AWG6)
Mounting torque max. 2.5 Nm Posidriv 2 bit
Power terminal screw M5
Housing Specifications Output Specifications
Rated operational current
AC51 @Ta=25ºC 50AACrms
Min. operational current 150mAACrms
Rep. overload current t=1 s
(Tj init.=25°C) < 200AACrms
Non-rep. surge current t=10 ms
(Tj init.=25°C) 1900A
p
Off-state leakage current,
@ rated voltage and frequency
< 3 mArms
I 2 t for fusing t=10 ms 18000A 2 s
On-state voltage drop @
rated current
1.6Vrms
Critical dV/dt off-state 1000V/µs
