2 NBOX/ENC2/S Electricty Meter Node Controller Installation Instructions TG200270 Issue 1/E 11/10/07
NBOX/ENC2/S Installation Instructions
172 mm (6.77")
209 mm (8.23")
104.5 mm
(4.11")
7 mm
(0.28")
1 2 3 4 5 6 7 8 9 1 0
T X R X
O K
1 2
3 Installation Instructions - Mounting
(continued)
Install EM-MPO/.. 3 4
Mounting
T X R X
O K D T R B D T R A
C T S B C T S A
T X R X
O K
1 2
E N C 2
Connecting Power
5
a
Ø 6 mm
(0.24”)
e f
Appropriate EM-MPO/..
Installation Instructions
EM-MPO/STAR3DIN TG200770
EM-MPO/STAR3 TG200771
EM-MPO/SIRIO TG200772
b
c d
~
2 3 0 V N C N O C
R D S / R S 2 3 2 ! 2 4 V
~
M O D E M
E N L
E N L
NBOX/ENC2/S consumption < =13 VA
WARNING: This apparatus must be earthed, grounded.
(via mains earth, ground, terminal)
DO NOT APPLY
POWER
0
I
~
not connected
Earth,
ground
the bus
bar
/230 version
/24 version 230 Vac
terminal size 0.5 to 2.5 mm 2 (14 to 20 AWG)
EJ
105383 24V
24 Vac:
24 Vdc:
24 Vac
Earth
+24V 0V
0V
Mat-N-Loc to
terminals adaptor
(supplied)
Ø 6 mm
(0.24”)
