TB/TS
Installation Instructions
TB/TS Thermistor Room Temperature Sensors Installation Instructions TG200604 Issue 1/E 14/02/07
4
Manufactured for and on behalf of the Environmental and Combustion Controls Division of Honeywell Technologies Sàrl, Ecublens, Route
du Bois 37,Switzerland by its Authorized Representative.
Trend Control Systems Limited reserves the right to revise this publication from time to time and make changes to the content hereof
without obligation to notify any person of such revisions or changes.
Trend Control Systems Limited
P.O. Box 34, Horsham, West Sussex, RH12 2YF, UK. Tel:+44 (0)1403 21888 Fax:+44 (0)1403 241608 www.trend-controls.com
Trend Control Systems USA
6670 185th Avenue NE, Redmond, Washington 98052, USA. Tel: (425)897-3900, Fax: (425)869-8445 www.trend-controls.com
I Q
Δ T
WEEE Directive :
At the end of their useful life the
packaging and product should be
disposed of by a suitable recycling
centre.
Do not dispose of with normal household waste.
Do not burn.
Test system
INSTALLATION
(continued)
Set up IQ Sensor types
9
tYpe Sensor digI/P Driver Function loGic Loop scHedule seQnc Analog
digBit Knob sWitch Time Zone Oss User addRess intcoN calarM reView Plot
calEndar
= ?
Thermistor (0 to +40 °C)
Yn
TYPE n
:
=?
S=5 (characterise)
Y=, E=, U=, L=, P=,
I1 to I6=, O1 to O6=
X
If IQL
10
If IQ
IQL Strategy Installation
Instructions
It is recommended to use SET (software tool) for the setting of sensor type modules.
For all IQ2 series controllers with firmware version 2.1 or greater, or IQ3 series controllers,
select the appropriate SET Unique Sensor Reference from the following:
Thermistor:
Thermistor TBTS (°C)
Thermistor TBTS F (°F)
If not using SET, use the following tables for all IQ2 series controllers of firmware version
2.1 or greater or IQ3 controllers; for all other IQ controllers see Sensor Scaling Reference
Card TB100521A.
