INSTALLATION

(continued)

Set up IQ Sensor types

10

tYpe Sensor digI/P Driver Function loGic Loop scHedule seQnc Analog

digBit Knob sWitch Time Zone Oss User addRess intcoN calarM reView Plot
calEndar

= ?

Thermistor (0 to +40 °C)

Yn
TYPE n
:
=?
S=5 (characterise)
Y=, E=, U=, L=, P=,
I1 to I6=, O1 to O6=
X

Knob (trim -3 to +3)

Yn
TYPE n
:
=?
S=5 (characterise)
Y=, E=, U=, L=, P=,
I1 to I4=, O1 to O4=
X

Fan Control (0 to 9.7)

Yn
TYPE n
:
=?
S=5 (characterise)
Y=, E=, U=, L=, P=,
I1 to I2=, O1 to O2=
X

It is recommended to use SET (software tool) for the setting of sensor type modules. For all IQ2
series controllers with firmware version 2.1 or greater, or IQ3 series controllers, the following SET
Part numbers should be used:

Knob:

Knob TB 3deg trim (guaranteed ±3 trim)

alternatively:

Knob T 3deg trim (±3 ±20% linear)

Thermistor:

Thermistor TBTS (°C)
Thermistor TBTS F (°F)

Fan control:

Fan Control V

If not using SET, use the following tables for all IQ2 series controllers of firmware version 2.1 or
greater or IQ3 controllers; for all other IQ controllers see Sensor Scaling Reference Card
TB100521A.

WEEE Directive :

DISPOSAL

Test system

11

I Q

/K

/O

/F

/OS

Δ T

Δ SP

Δ

yellow

green

At the end of their useful
life the packaging and
product should be
disposed of via a suitable
recycling centre.

Do not dispose of with normal household
waste. Do not burn.
