WS/S, /SD Installation Instructions
WS/S, /SD Installation Instructions TG102613 Issue 2/C 08/01/07 4
Manufactured for and on behalf of the Environmental and Combustion Controls Division of Honeywell Technologies Sàrl, Ecublens, Route
du Bois 37,Switzerland by its Authorized Representative.
Trend Control Systems Limited reserves the right to revise this publication from time to time and make changes to the content hereof
without obligation to notify any person of such revisions or changes.
Trend Control Systems Limited
P.O. Box 34, Horsham, West Sussex, RH12 2YF, UK. Tel:+44 (0)1403 21888 Fax:+44 (0)1403 241608 www.trend-controls.com
Trend Control Systems USA
6670 185th Avenue NE, Redmond, Washington 98052, USA. Tel: (425)897-3900, Fax: (425)869-8445 www.trend-controls.com
WEEE Directive :
At the end of their useful life the packaging
and product should be disposed of by a
suitable recycling centre.
Do not dispose of with normal household waste.
Do not burn.
Installation (continued)
Set up IQ Wind
Direction Strategy
11
Set up IQ Wind Speed Strategy
12
Test System
13
Check Sensor Alignment
14
see WS/S, /SD Data Sheet
TA102481
S 1 7
3 6
E
F
F 1 4
D I V
D
3 5
G
1 1 4
1 . 4 9 3
W i n d S p e e d
3 4
9 4
9 3 G 1
C O U N T E R
1 , 0
1
W i n d S p e e d
R
M
S
F = 1
S T = 6 0
6 0
i n m / s
D = F ( G / E )
r e s e t
The diagram shows digital input 1 being used; the strategy
should be changed to match the actual input channel used.
Δ V
Δ D
N
S
E W
if greater accuracy required
N
IQ
IQ
Δ D=360°/0°
For IQ1xx, IQ2xx (
Disposal
For S17 to be in feet/second
set F14(F) to 4.75.
