22 923662 Rev B
T EST T YPE [C OMPLIANCE |95% C ONFIDENCE ]
The Compliance setting uses 2 minutes and 5 seconds (1e12 bits) limit with 0 or 1 error for pass
criteria during Rx BER testing. The 95% Confidence setting uses a 6 minutes and 15 seconds
(3e12bits) limit with no errors for pass criteria, which is 95% confidence at 1e-12 BER testing.
QPHY-PCIE3-TxRx Limit Sets
The default installation of QPHY-PCIE 3-TxRx contains only one limit set, called “Default.” In
this script, limits are only used to convey Unit labels. The actual limits for each value tested are
encoded in or computed by the script and cannot be changed. The default limits used by QPHY-
PCIE3-TxRx are specified in the PCI Express Card Electromechanical Specification, Rev. 3.0.
