Teledyne LeCroy Automation API Reference Manual for USBTracer, USB Advisor, and Voyager USB Protocol
Suite
37
2.3 IUsbAnalyzer4 interface
The IUsbAnalyzer4
interface is the forth interface for the UsbAnalyzer object. It inherits and extends
some analyzer-related functionality exposed via the IUsbAnalyzer
interface.
IID : D793E9EE-58EE-4237-9D2A-41DBB61DCDF8
2.3.1 IUsbAnalyzer4::GetRecordingStatus
HRESULT GetRecordingStatus (
[
out
] VARIANT* is_trigged,
[
out
] VARIANT* is_done);
This method could be used to poll recording state of analyzer after recording start. The method returns
useful running state information like happening trigger condition and recording finish. User may use this
method to poll status of recording and go to next step according to polling result.
Parameters
is_trigged
Pointer to boolean variable indicating analyzer triggered or not.
is_done
Pointer to boolean variable indicating recording process is finished or not
Return values
ANALYZERCOMERROR_ANALYZERNOTCONNECTED
Analyzer is not connected
Remarks
A new method named as WaitForRecordingStatus is added to Anlyzer interface that could be used
instead of this method. The new method doesn’t block software normal operation and recommended to
use new method.
2.3.2 IUsbAnalyzer4::ResetUsb3Trainer
HRESULT ResetUsb3Trainer ([
in
]
int
is_device_mode);
This
method reset and initialize analyzer unit in “Host” trainer or “Device” trainer modes without runnig
any script.
Parameters
is_device_mode
Specify desired mode.
“1” for “Device” mode, “0” for “Host” mode
Return values
ANALYZERCOMERROR_ANALYZERNOTCONNECTED
Analyzer is not connected
Remarks
