Teledyne LeCroy Automation API Reference Manual for USBTracer, USB Advisor, and Voyager USB Protocol
Suite

27

2.1.14 IUsbAnalyzer::StartUsb3Generation

HRESULT StartUsb3Generation([

in

,

defaultvalue

("")] BSTR gen_file_name);


Starts generating USB traffic.

Parameters

gen_file_name

USB 3.0 Exerciser script file name to execute.
If this parameter is an empty string, the last executed
script is repeated.

Return values

ANALYZERCOMERROR_ANALYZERNOTCONNECTED

No Analyzer connected


ANALYZERCOMERROR_UNABLESTARTGENERATION

Analyzer cannot start for one of

the following reasons:
- Script has compiling error.
- Analyzer is currently running or paused.
- Analyzer is currently used by another client.
- License for trainer device was not purchased.
- USB 2.0 generation is running.

Remarks

This function returns after generation starts. Analyzer continues generating until it finishes or until the
StopUsb3Generation or PauseUsb3Generation method call is performed.

During generation, events are sent to the event sink (see the

_IAnalyzerEvents interface

section).


The script file should have the f

ile extension “.usb3g”. It can be created by either the USB Protocol Suite

text editor or any plain-text editor.
