Packet Properties Properties and Programmatic Settings
CATC IBTrainer InfiniBand Exerciser API Reference 4-19
The Atomic ACK Extended Transport Header is present in all Atomic
ACK packets.
Table 22 Atomic ACK Extended Transport Header Property List
Property Name Range Default Description
AtomicAckETH_OrigRemDt
0 – 2 64 0 Original Remote Data.
The Immediate Data Extended Transport Header is present in the last
packet of a request with immediate data.
Table 23 Immediate Data Extended Transport Header Property List
Property Name Range Default Description
ImmDt
0 – 2 32 0 Immediate Data.
The payload for the packet either comes out of a PRBS (generic packet
property) or is handed to the software as a pointer to a data array. Only
one behavior is needed to specify the payload size. This is controlled by
a generic packet property.
The software calculates the invariant CRC and the variant CRC
automatically. Generic packet properties are available to let you create
incorrect CRCs.
