Properties and Programmatic Settings Packet Properties
4-16 CATC IBTrainer InfiniBand Exerciser API Reference
Base Transport Header Properties
This header is present in all packets.
Table 16 IGCIBAPacket::Prop: Base Transport Header Properties
Property Name Range Default Description
BTH_OpCode IGCVal::Opcode
0
Opcode. To use a reserved opcode
specify the value as
ig_int32.
BTH_SE
0 - 1 0 Solicited Event.
BTH_M
0 - 1 User Migration State.
BTH_PadCnt
0 - 4 Pre-calculated Pad Count.
BTH_TVer
0 - 16 0 Transport Header Version.
BTH_P_KEY
0 - 65535 0 Partition Key.
BTH_Reserved32
0 - 255 0 Reserved (variant).
BTH_DestQP
0 – 2 24 0 Destination QP.
BTH_A
0 - 1 0 Acknowledge Request.
BTH_Reserved65
0 - 128 0 Reserved.
BTH_PSN
0 – 2 24 0 Packet Sequence Number.
