Properties and Programmatic Settings IGCNodeInfo Properties
4-6 CATC IBTrainer InfiniBand Exerciser API Reference
IGCNodeInfo Properties
The IGCNodeInfo properties are determined by the list of values kept in
the struct NodeInfo for each InfiniBand port. A complete description is
available in the InfiniBand Specification, Section 14.2.5.3.
Table 8 List of IGCNodeInfo Properties
Property Name Range Default Access Description
BaseVersion
0 – 2 8 1 RO Supported MAD Base Version
ClassVersion
0 – 2 8 1 RO Supported Subnet Management Class
Version
Type
0 – 2 8 1 RO The default is to emulate a channel
adapter (=1);
NumPorts
0 – 2 8 1 RO Number of physical ports on this node
Reserved32
0 – 2 64 0 RO Reserved, shall be zero
GUID
0 – 2 64 0 RO GUID of the end node
PortGUID
0 – 2 64 0 RO GUID of this port itself
PartitionCap
0 – 2 16 1 RO Entries in partition table
DeviceID
0 – 2 16 0x2953 RO Assigned by manufacturer
Revision
0 – 2 32 1 RO Device Revision
LocalPortNum
0 – 2 8 1 RO Link Port number for this SMP
VendorID
0 – 2 24 0x15bc RO Device vendor (IEEE)
