ZD200 Differential Probe
14 922182-00 Rev A
11. Connect the signal generator output to the ZD200 inputs using the BNC
to mini-grabber cable.
12. Read the voltage from the DMM and record this value on the test data
sheet.
13. Record the calculated error to two decimal places (±0.xx%) as "Gain
Error" in the test record.
14. Verify that the error is less than ±1.0 %.
This completes the Performance Verification of the ZD200. Complete and file the
Test Record, as required to support your internal calibration procedure.
Apply suitable calibration label to the ZD200 housing as required.
Performance Verification Test Record
This record can be used to record the results of measurements made during the
performance verification of the ZD200 Probe. Photocopy this page and record
the results on the copy. File the completed record as required by applicable
internal quality procedures. The section in the test record corresponds to the
parameters tested in the performance verification procedure. The numbers
preceding the individual data records correspond to the steps in the procedure
requiring the recording of data.
Results to be recorded in the column labeled Test Result are the actual
specification limit check. The test limits are included in all of these steps. Other
measurements and the results of intermediate calculations that support the limit
check are to be recorded in the column labeled Intermediate Results.
Permission is granted to reproduce these pages for the purpose of recording test
results.
NOTE: Use a new Test Record for each tested probe, probe tip module, and lead
assembly.
