Getting Started Manual
922182-00 Rev A 5
Number Part Description
1 Hook Clips
2 Micro-Grabbers
The micro- and mini-grabbers are ideal for
connecting to small IC legs or pins very
tightly spaced.
3 Micro IC Grabbers
The micro- and mini-grabbers are ideal for
connecting to small IC legs or pins very
tightly spaced.
4
Straight Tips and
Dual Pin Sets
The Straight Tip and Dual Pin Sets are
designed to connect to the smallest vias
and small test points. Fits in either probe
socket.
5 Extension Leads
This lead has a socket on one end and a
square pin on the other to connect to the
input or ground socket of the probe body,
and may be used for general purpose
probing.
6 Y Lead Adapter
This lead is used for both ground and
input lead simultaneously. It has two
sockets on one end for connection to the
provided hook clips and two square pins
on the other and may be used for general
purpose probing.
