ZD200 Differential Probe
10 922182-00 Rev A
Performance Verification
Performance Verification Overview
This procedure can be used to verify the warranted characteristics of the ZD200
High Impedance Active Probe.
The recommended calibration interval for the model ZD200 is one year. The
complete performance verification procedure should be performed as the first
step of annual calibration. Test results can be recorded on a photocopy of the
Test Record provided in Appendix A at the end of the manual.
Performance verification can be completed without removing the probe covers
or exposing the user to hazardous voltages. There are no adjustments.
This procedure tests LF Attenuation Accuracy.
Required Test Equipment
The following table lists the test equipment and accessories (or their
equivalents) that are required for performance verification of the ZD200 Probe.
This procedure has been developed to minimize the number of calibrated test
instruments required.
Only the parameters listed in boldface in the Minimum requirements column
must be calibrated to the accuracy indicated.
Because the input and output connector types may vary on different brands and
models of test instruments, additional adapters or cables may be required.
