Teledyne LeCroy ZD200 User Manual
Page 17

Getting Started Manual
922182-00 Rev A
11
List of Required Test Equipment.
Description
Minimum Requirement
Test Equipment Examples
Digital Oscilloscope
ProBus Interface
Windows-based with
software version 6.4.1.5
or later
Teledyne LeCroy
WaveRunner Xi, WavePro
7 Zi or WaveSurfer Xs
Digital Multimeter
(DMM) with test
probe leads
4.5 digit
DC: 0.1% Accuracy
AC: 0.1% Accuracy
Agilent Technologies
34401A
Fluke 8842A-09
Function Generator
Sine Wave output
amplitude adjustable to
14.14 Vp-p (5 Vrms) into
1 MΩ at 70 Hz
Agilent Technologies
33120A
Stanford Research Model
DS340
Power Supply
0-12 V, settable to 10 mV HP E3611A
BNC Coaxial Cable
(2 ea.)
Male to Male, 50 Ω, 36"
Cable
Pomona 2249-C-36
Pomona 5697-36
BNC Tee Connector
Male to Dual Female
Pomona 3285
Calibration Fixture
ProBus Extender Cable
Teledyne LeCroy
PROBUS-CF01
Terminator,
Precision, BNC
50 Ω ± 0.05%
Teledyne LeCroy
TERM-CF01
Banana Plug
Adapter (2 ea.)
Female BNC to Dual
Banana Plug
Pomona 1269
BNC to Mini-grabber BNC Mail to Mini-grabber
Cable, 36”
Pomona 5187-C-36
