Teledyne LeCroy WaveAce - Manual (Page 81)

WaveAce Series
81 WA-GSM-E RevB
The SELF TEST screen is shown.
Note: After using an option button to select either the Do Self
Test, and Print Setup (when enabled) functions, more options are
then shown. You can return to the original menu from this second
level by pressing the UTILITY front panel button.

Choose from Screen, Keyboard, or LED tests.

After making your selection a corresponding screen is shown where
either the SINGLE or RUN/STOP front panel button is used to
complete the test and/or exit the test screen. Test screens look like
the following:
Figure 4-5. Each press of the SINGLE front panel button runs successively
through colors and is how the Screen Test is performed. Move through a
few colors until you are satisfied. As the screen indicates, press the
RUN/STOP front panel button to exit.
