Getting Started Manual
WA-GSM-E RevB 14
WARNING - Electrical Shock Hazard
Only use the power cord provided with your instrument.
Any interruption of the protective conductor inside or outside of the
oscilloscope, or disconnection of the safety ground terminal creates a
hazardous situation. Intentional interruption is prohibited.
In Standby mode, the oscilloscope is still connected to the AC supply. The
instrument can only be placed in a complete Power Off state by physically
disconnecting the power cord from the AC supply or by flipping the main
power switch on the back of the oscilloscope to the off (Zero) position (on
4 channel models).
CAUTION
The outer shells of the front panel terminals CH1, CH2 (or CH3 and CH4 on
4 channel models), and EXT TRIG are connected to the instrument’s chassis
and therefore to the safety ground.
Fuse Replacement
(4 Channel Models Only)
Set the instrument Standby (power) switch to Standby mode, flip the
mains power switch to the OFF (0) position, and disconnect the power cord
before inspecting or replacing the fuse. Open the black fuse holder
(located at the rear of the instrument below the main power switch) using
a small, flat-bladed screwdriver. Remove the old fuse, replace it with a new
5 X 20 mm T rated 1.25 A/250 V fuse, and reinstall the fuse holder.
WARNING
For continued fire protection at all line voltages, replace fuse with the
specified type and rating only. Always disconnect the power cord before
replacing the fuse.
