BASICS 38
Software Options
You may purchase these optional software packages to enhance the
operation of an HDO6000 Oscilloscope.
Available Software Options
Power Analysis Option (HDO6K-PWR) — Provides exceptional ability
to measure and analyze the operating characteristics of power
conversion devices and circuits. The Power Analysis option is used with
Teledyne LeCroy oscilloscopes to make critical power switching device
measurements, perform control loop modulation analysis, and measure
line power harmonics.
JITKIT (HDO6K-JITKIT) — JITKIT makes it easy to understand the
basic system jitter performance of clock signals and clock-data activities,
including period, half period, cycle-cycle, skew, amplitude, differential
voltage crossing, slew rate, and a wide variety of common jitter
measurements.
Serial Trigger/Decode and Other Options (see table at right) — There
are many serial trigger and decode options available that provide added
insight when debugging particular serial data standards. For the most up
to date list, go to teledynelecroy.com/serialdata.
How to Purchase and Install Options
To purchase an option, contact your Teledyne LeCroy sales representative
at the number listed in this guide. You will receive a license key via email
that activates the optional features on the oscilloscope. To install the key:
1. Go to Utilities > Utilities Setup > Options.
2. Touch Add Key.
3. Enter the new license key and click OK.
4. Reboot the oscilloscope software.
Part Number Description
HDO6K-1553 TD MIL-STD-1553 Trigger and Decode Option
HDO6K-ARINC429BUS Dsymbolic ARINC 429 Symbolic Decode Option
HDO6K-Audiobus TD/TDG Audiobus Trigger and Decode Options for
I
2 S, LJ, RJ and TDM
HDO6K-CANbus TD/TDM Can Trigger and Decode Options
HDO6K-DFP2 Digital Filter Package
HDO6K-DigRF3Gbus D DigRF 3G Decode Option
HDO6K-DigRFv4bus D DigRF v4 Decode Option
HDO6K-DPHYbus D D-PHY Decode Option
HDO6K-EMB I 2 C, SPI, UART and RS-232 Trigger and Decode
HDO6K-EMC Electromagnetic Compliance Package
HDO6K-ENETbus D 10M and 100M ENET Decode Option
HDO6K-ET-PMT Electrical Telecom Mask Test Package
HDO6K-FlexRaybus TD/TDP FlexRay Trigger and Decode Options
HDO6K-I2Cbus TD I 2 C Trigger and Decode Option
HDO6K-LINbus TD LIN Triggewr and Decode Option
HDO6K-Manchester D Manchester D Decode Option
HDO6K-NRZ D NRZ Decode Option
HDO6K-PROTOBUS MAG PROTOBUS MAG Decode Option
HDO6K-SDM Serial Data Mask Package
HDO6K-SENTbus D SENT Decode Option
HDO6K-SPIbus TD SPI Trigger and Decode Option
HDO6K-UART-RS232bus TD UART and RS232 Trigger and Decode Option
HDO6K-USB2bus D USB 2.0 Decode Option
HDO6K-USB2-HSICbus D USB-HSIC Decode Option
HDO6K-VBA Vehicle Bus Analyzer Option
HDO6K-XDEV Advanced Customization Package
