Steelcraft Automotive 80400 REAR BUMPER SPORT TUBES User Manual
Page 3
SINGLE TUBE REAR BUMPER GUARD
2010 EQUINOX/TERRAIN
Page 3 of 3
7/20/10 Rev1(DP)
Driver Side Installation Pictured
(2) 12mm x 35mm Hex Bolts
(4) 12mm Flat Washers
(2) 12mm Nylon Lock Nuts
(2) 8mm x 25mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers
Rear
Fig 4A
Fig 4B
For additional width adjustment,
insert (1) Spacer between each
Frame Bracket and Mounting
Bracket to move Brackets inward
Fig 5
Complete Installation
