Driver side installation shown) – Steelcraft Automotive 84147 REAR BUMPER SPORT TUBES User Manual
Page 3
Installation Complete
(Driver Side Installation Shown)
Page 3 of 3
11/6/07
(AM)
12-1.25mm x 40mm Hex Head Bolts
(fine thread)
12mm Lock Washers
12mm Flat Washers
12-1.75mm x 40mm Hex Head Bolts
12mm Lock Washers
12mm Hex Nuts
12mm Flat Washers
8mm x 20mm Hex Head Bolts
12mm Lock Washers
12mm Flat Washers
Fig 3
Fig 4
Fig 5
Fig 6
Fig 7
