5IN BENT END SIDEBAR
99-12 FORD F-250/450 SUPERDUTY CREW CAB
Page 2 of 2 1/5/12 (DP)
8. Level and adjust Sidebar properly and tighten all hardware.
9. Repeat Steps 2
– 8 for passenger Sidebar installation.
10. Do periodic inspections to the installation to make sure that all hardware is secure and tight.
To protect your investment, wax this product after installing. Regular waxing is recommended to add a
protective layer over the finish. Do not use any type of polish or wax that may contain abrasives that could
damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild
soap may be used also to clean the Sidebar.
For gloss black finishes: Mild soap may be used to clean the Sidebar.
Driver Side Installation Pictured
8mm x 30mm Hex Bolts
8mm Lock Washers
(2) 8mm Flat Washers
8mm Hex Nuts
8mm Clip Nuts
8mm x 30mm Hex Bolts
8mm Lock Washers
8mm Flat Washers
8mm x 25mm Hex Bolts
8mm Lock Washers
8mm Flat Washers
(Fig 1) Typical Mounting Location
Fig 2
Fig 3 Fig 4
Factory holes in pinch weld
Factory holes in pinch weld
Line up Clip Nut
with factory hole
Rear
Front
