Steelcraft Automotive 232700 3 ROUND SIDE BAR - Manual (Page 4)

SIDEBARS
08-12 TOYOTA HIGHLANDER (GAS & HYBRID)
Page 4 of 4 2/18/11 (DP)Rev C
(Fig 8A) Add Spacer for 2011 Vehicles Only
(Fig 8B) Front Spacer
for 2011 Only
(Fig 10B) Rear Spacer
for 2011 Only
Fig 9A
(Fig 9C) 12mm
Double Nut
Fig 9B
Fig 11
Driver Side Installation Pictured
(Fig 10A) Add Spacer for 2011 Vehicles Only
8mm x 25mm Hex Bolts
8mm Lock Washers
8mm Flat Washers
Installation
Complete
12mm x 90mm Bolt Plate
12mm x 90mm Bolt Plate
12mm Lock Washer
12mm Double Nut
Front
Rear
Rear
Rear
