Steelcraft Automotive 155110 RUNNING BOARD User Manual
Page 3
VIEWPOINT RUNNING BOARDS
2009-13 HONDA PILOT
Page 3 of 5
2-13-13(DP)
Driver Side Installation Pictured
(Fig 1) Driver side front mounting location pictured
Fig 2
Locate (2) factory
8mm threaded holes
Front
Front
(Fig 3) 10mm Bolt Plate
Fig 4
Fig 5
Front
Front
(2) 8mm x 25mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers
10mm Bolt Plate
10mm Flat Washer
10mm Lock Washer
10mm Hex Nut
(2) 10mm x 35mm Hex Bolts
(4) 10mm Flat Washers
(2) 10mm Lock Washers
(2) 10mm Hex Nuts
