Steelcraft Automotive 71390 BULL BAR User Manual
Page 3
BULL BAR
2011 FORD EXPLORER
Page 3 of 5
6/17/11 (DP)
Driver Side Installation Pictured
12mm x 50mm Hex Bolt
12mm Lock Washer
12mm Flat Washer
Spacer Plate
Fig 3A
(Fig 5A) Passenger side installation pictured
Fig 4
Fig 3B
12mm Lock Washer
12mm Flat Washer
12mm Hex Nut
Front
Front
Front
Forward
Fig 5B
Fig 5C
