3
1 Via_GK2 1 gk2
35H35H 35H
Delete
2
GK2_3_1
2 gk2_3_1
36H36H 36H
Delete
3 GK_ALL 3 gk
37H37H 37H
Delete
By Index 1, if user input any phone number with prefix code is 1, The VoIP
Gateway will call out via Gatekeeper 2.
By Index 2, if user input any phone number with prefix code is 2, The VoIP
Gateway will try to call out by Gatekeeper 2 ( if register to Gatekeeper 2 is
successful), if Gatekeeper 2 is not available, it will check Gatekeeper 3, then
check Gatekeeper 1.That mean if register to gk2 is failure and register to gk3 &
gk1 is successful, the VoIP Gateway will call out via gk3.
You can check the Gatekeeper register status on /VoIP Setup/Register
Server/Register Status.
f. Call to different IP port
The default IP port used by VoIP Gateway is 1720 for H.323 and 5060 for SIP, if
work with remote side of VoIP Gateway or gateway is change another port
number for VoIP, please assign another port number after destination IP or URL.
Please make sure both side use same port number for VoIP call, otherwise it can
not make call. You can change the VoIP Gateway default listen port on .
Index Remark Area Code Min Digits Max Digits IP Address Strip Prefix Profile Delete
1 Port_1719 1 10.1.1.1:1719
38H38H 38H
Delete
2 Port_8495 2 China.proxy.com:8495
39H39H 39H
Delete
g. Profile:
Define the optional special VoIP parameters when calling to the destination.
Please input the name you defined on the profile ( /VoIP Setup/Routing
Setup/Routing Profile/ ) list.
Example: if user set the VoIP Call Out & Routing Profile like below:
Index Remark Area Code Min Digits Max Digits IP Address Strip Prefix Profile Delete
1 UsePF1 1 gk1 PF1
40H40H 40H
Delete
