3
Index Remark Area Code Min Digits Max Digits IP Address Strip Prefix Profile Delete
1 Take_All 86 10.1.1.1
2 Never_Used 8621 20.1.1.1
d. Strip and Prefix
User is easy to combine using Strip and Prefix define to modify the phone
number from phone to real call out phone number, for example, if the VoIP
Gateway is installed on Taipei and use another Gatekeeper to service global
service. When user just dial 10 digits Taipei phone number like 02-12345678(do
not need to press # key because Max Digits setting is 10), and the VoIP
Gateway will stripe the 02 ( 2 digits defined on Strip) ,add the country code
8862 (defined on Prefix) then send 8862-12345678 out for VoIP call, see below
example:
Index Remark Area Code Min Digits Max Digits IP Address Strip Prefix Profile Delete
1 Taipei 02 10 Gk 2 8862
34H34H 34H
Delete
By above setting, When you dial 0212345678, you can check the real call out IP
and phone number will change to 886212345678 at the VoIP Setup/ Port
Status:
Port Message
Port Type
Display
name
Status Connected IP Caller ID Start Time End Time
Talking
Sec
Dialed number Release by
1 FXS Idle 172.16.7.1
2004/02/19
13:55:10
2004/02/19
13:55:43
28 886212345678 (146)onHangup
2 FXS Idle
e. Call via Gatekeeper/ SIP Register server
This VoIP Gateway can register up to 4 servers, for example:
Index Remark
Area
Code
Min
Digits
Max
Digits
IP Address Strip Prefix Profile Delete
NEVER
