LEESON FHP Series NEMA 4x Variable Speed Drive - Manual (Page 5)

iv General Information
Figure 1. F HP Series Features & Benefits
STANDARD ISOLATION
ACCEPTS A 0 - 5 VDC,
0 - 10 VDC, or 4 - 20 mA
NON-ISOLATED SIGNAL
VOLTAGE DOUBLER
DOUBLES THE OUTPUT
VOLTAGE TO THE AC
MOTOR WHEN 115 IS APPLIED
ADJUSTABLE
CALIBRATION
TRIMPOTS
DECEL
ACCEL
MAX
BOOST
TQ LIMIT
LED INDICATORS
POWER
(green)
ENABLE
(red)
FAULT
(red)
• SOLID-STATE CIRCUITRY
• SOLID-STATE REVERSING
• ADJUSTABLE CARRIER FREQUENCY (4 kHz - 16 kHz)
• MULTIPLE MOTOR OPERATION
• THREE-PHASE AND SINGLE-PHASE MOTOR CONTROL
F HP SERIES FEATURES & BENEFITS
MIN
SLIP COMP
ZERO SET
TORQUE
(yellow)
BRAKE
TIME
BRAKE
CURRENT
