12
Warning
DO NOT connect this equipment with power
applied. Failure to heed this directive may result in
fire or serious injury.
LEESON
strongly recommends the installation of a
master power switch in the voltage input line. The
switch contacts should be rated at a minimum of 200%
of motor nameplate current and 250 volts.
ƽ
Input AC Power connections
Connect the AC power input to TB502 L1 and L2 as shown
in Figure 5 (page 13). Connect an external master stop
switch. Install the switch between the external AC power
input as shown.
Connections
All power input and power output connections are made to
TB502.
