LEESON FHP Series NEMA 4x Variable Speed Drive - Manual (Page 10)

1
Specifications
1-Phase 1 or 3-Phase Max Continuous AC
Input Output Max Output Amps
Drive (VAC) (VAC) HP Current (AC) In
175326.00 *115/230 230 1 4.0 14/7
*
Connect only 115 VAC line input to the 115 VAC terminals. Application of 230 VAC line input when set for 115
VAC will result in severe damage to the motor and drive, and possible explosion and injury.
† Derate current by 2% per degree if the operating temperature is above 40°C. Under no circumstances may the
ambient temperature exceed 55° C.
AC Voltage Input Range 115/230 VAC ± 10%, 50/60 Hz single phase
Standard Carrier Frequency
16 KHz
Output Frequency Range 0 – 120 Hz
Maximum Output Frequency Range 30 – 120 Hz
Minimum Output Frequency Range 0 – 30 Hz
Acceleration Time Range
1 – 12 seconds
Deceleration Time Range 1 – 12 seconds
Analog Input Voltage Range 0 – 5VDC,0-10VDC,4-20mA**
Input Impedance, S1 to S2 ~ 100K ohms
Braking Current 0-100% rated output
Braking Time 1 – 12 seconds
Vibration 0.5G max (20 – 50 Hz)
0.1G max (> 50 Hz)
Weight 1.2 lb
Ambient Operating Temperature Range 10° – 40° C
** Isolation is standard, and allows for non-isolated speed input, enable and direction switch inputs to be used.
