LEESON FHP Series NEMA 4x Variable Speed Drive User Manual
Page 31
22
Operation
Warning
Dangerous voltages exist on the drive when it is
powered, and up to 60 seconds after power is
removed and the motor stops. BE ALERT. High
voltages can cause serious or fatal injury.
Do not change jumper settings with power applied.
Ensure that jumper settings are compatible with the
motor being controlled.
ƽ
▵
Voltage Input Warning
DO NOT connect 230 VAC line input when the
drive is set for 115 VAC input. This will result in
severe damage to the motor and drive, and possible
explosion and/or injury.
ƽ
▵
