4
ASP-MG24
1.0 INTRODUCTION
The Atlas Sound ASP-MG24 is a 2 input by 4 output digital loudspeaker management system and
masking generator designed for fixed sound installation markets. The ASP-MG24 features the latest in
available technology utilizing a 32-bit (40-bit extended) floating point processors and high performance
24-bit Analog Converters. Both balanced inputs are mic/line selectable along with 4 addition independent
masking generator input sources. Inputs and outputs can be routed or mixed in multiple configurations
to meet even the most complex system designs. Control parameters include I/O levels, delay, polarity,
parametric EQ, crossover selections, 31 band EQ, White/Pink Noise, Auto Ramp, routing, mixing and
compressor/limiters. The ASP-MG24 can be controlled or configured in real time with the intuitive PC GUI,
accessed via the RS-232 or USB interface. Software upgrade for CPU and DSP via PC always keeps the
ASP-MG24 current. Optional masking scheduler and programmable remote control is also available.
2.0 FEATURES
•
2 Mic/Line Inputs and 4 Outputs
•
System routing and mixing flexibility
•
4 Independent Random Pink or White Noise Generators
•
8 Parametric Filters for each Input and Output
•
Multiple Crossover types up to 48dB
•
Full Function Compressor Limiters
•
Four 1/3rd Octave Graphic Equalizers for Masking
•
User set masking auto ramp
•
Precise Level, Polarity and Delay
•
Full 5-segment LED’s on every Input and Output
•
Storage of up to 30 Program Setups
•
Multiple Levels of Security Locks
•
Optional Advance Masking Scheduler
•
Optional Programmable System Controller
•
RS-232 & USB Interface for PC Control and Configuration
•
CPU and DSP upgrade via PC
