24
ASP-MG24
Option Graph Sub Screen Window – In the top right corner of the window there is Option button. This window
allows you to view multiple channels of filters. Graph viewing scale. The Reset button will set all filters back to
factory settings. This Reset button only effects this screen settings
Graph Sub Screen Window – In the top right corner of the window there is option button. This window allows
you to view multiple channels of filters. Graph viewing scale. The Reset button will set all filters back to factory
settings. This Reset button only effects this screen settings
Audio Control Parameters
•
Gain: -40dB to +15dB in 0.25dB steps
•
Polarity: +/-
•
Delay: Up to 200ms per I/O
•
Parametric Filters (8 per I/O)
•
Hi-shelf, Lo-shelf Filters
•
Filter Bandwidth: 0.02 to 2.50 octaves (Q=0.5 to 72)
•
Masking Inputs
o
4 Independent generators
o
White or Pink Noise
o
31 Band EQ per output
o
Parametric Filters, Crossover, Gain per output
o
Turn on Auto ramp 0:00 – 10:00 min
•
Crossover Filters (2 per Output)
o
Filter Types: Butterworth, Bessel, Linkwitz Riley
o
Slopes: 6 to 48dB/oct
•
Compressor / Limiters
o
Threshold: -20 to +20dBu
o
Ratio: 1:40
o
Attack: 0.3 to 100ms
o
Release: 2 to 32X the attack time
System Parameters
•
No. of Programs: 30
•
Program Names: 12 character length
•
Delay Units: ms, ft, m
•
Security Locks: System
PASSWORD – The password of the ASP-MG24 is 4 characters in length. The user can change it via the PC
application software. The factory default of a new unit does not require a password
