Adjustable Electronic Thermostat TRACON
®
Model SST–3 (P/N 24492)
Instruction Manual
24494 Rev. - 04/12 (800) 234-4239 http: www.networketi.com Environmental Technology, Inc. 26 of 28
SPECIFICATIONS
GENERAL
Areas of Use Nonhazardous
Approvals
 UL Listed to UL 1053 Ground-Fault
Sensing and Relaying Equipment
ENCLOSURE
Protection IP 66 NEMA 4X
Dimensions
5 1/4” (L) x 8” (W) x 4 1/16” (H)
133.2mm (L) x 203.2mm (W) x 103.2mm (H)
Material Polycarbonate
Cover Attachment
Polycarbonate cover, machine screws
Weight 3 pounds (1.4kg)
Mounting Wall Mount
Cable Entries
4: incoming power cable @ 1.05”; (27mm)
outgoing heater cable @ 1.05”; (27mm)
outgoing alarm relay @ 1.05”; (27mm)
incoming temperature probe @ 0.67” (17mm)
FRONT PANEL INTERFACE
Status Indicator
SUPPLY (green): Power on
HEAT (yellow): Heating cycle in progress
GFEP (red): Ground fault condition
GFEP (red, rapid flashing): GFEP test in progress
