OPERATION
This section presents operating instructions for the unit and begins with a picture
of the front panel. Refer to Figure 5. Note the system information located on the
left side of the panel, as well as the operator controls and indicators on the right
side of the panel. The controls and indicators are explained in this section.
Figure 5. THE SST–3 FRONT PANEL.
Note that because the unit has no ON/OFF power switch, power runs to the unit
as soon as facility power is connected to it. For as long as power is running to
the unit, the green SUPPLY LED will always be lit. The unit initiates a heating
cycle when the temperature probe detects a temperature of less than the set
point and remains on until a temperature 2 degrees Fahrenheit or 1 degree
Centigrade above the set point is detected.
Note the information
presented here.
Operator Controls
and Indicators
