KB Electronics KBPW-240D User Manual
Page 8
5
BRK
REV
FWD
0.357
[9.07]
8.876
[225.45]
8.226
[208.94]
5.472
[138.99]
5.886
[149.50]
%
100
90
80
70
60
50
40
30
20
10
0
NEMA-4X / IP-65
START
STOP
RUN
JOG
PWM DC MOTOR SPEED CONTROL
P
ENTA
-D
RIVE
™
OL
STOP
ON
™
5.000
[127.00]
9.488
[241.00]
CONTR
OL SHO
WN
WITH OPTIONAL FWD-BRK-REV AND R
UN-ST
OP-JOG SWITCHES
FIGURE 2 – MECHANICAL SPECIFICATIONS (INCHES / [mm])
