Inter-M HDRC-Z440 - Manual (Page 30)

Electrical
Input Voltage
24VAC / 12VDC ± 10%
Power Consumption 18W (1.5A)
Control
RS-485 baud rate: 2400~38.4k bps
(default: 9600bps)
ID (Camera Address) 3999
Mechanical
Dimension
See Figure below
Weight Approx 1.2 kg
Pan Angle 360° continuous rotation
Speed 0.1° to 380°/sec. (proportional to zoom)
380°/sec. maximum (with CTRL key pressed)
Preset Speed: 380°/sec
Flip 180° Digital Flip or 90° Auto Flip.
Autoscan 16 auto scans and one endless panning
Preset Position 240 positions with camera status (6-character title)
Tour 8 tours
Pattern 8 patterns, up to 500 second
Privacy Zone 12 Privacy Zones
On-Screen Display Displays camera ID and Pan & Tilt Angle
Environment
Operating temperature
0°C to 50°C (32°F to 122°F)
Operating humidity 0 to 90%RH (non-condensing)
Storage temperature -20°C to 60°C (4°F to 140°F)
Figure 11 – Dimension
