3.8 Pattern
(Shortcut: PTRN)
The Pattern feature records user control of the selected dome camera. Up to four 8 patterns can be stored
and played back by pressing No.+ PTRN keys subsequently.
Follow steps below to program the Pattern:
1. Press MENU to display the main menu on the monitor. Scroll to Pattern and push the Joystick to the
right to enter the pattern menu. Or just press the PTRN key on the keyboard.
2. Select the desired pattern to be programmed by pushing the Joystick Up or Down. If the pattern is not
000, a pattern has already been recorded. Patterns can be overwritten.
3. Press and hold down the CTRL key while controlling the camera direction and zoom with the Joystick.
The dome will be automatically recorded until you release the CTRL key. Or Press IRIS Open then the
“CTRL” displays. Move the position and the zoom position. Press IRIS Close then the “CTRL”
disappears.
4. Select Save and Exit and push the Joystick to the right. Press ESC to exit the program without saving.
5. To edit the title, follow the procedure of the auto scan above to edit titles.
NOTE: Press the HOME key at any programmed position to delete the pattern.
NOTE: If total recording time reaches 500 seconds, it will automatically stop for a moment.
Press PTRN key on the title field to display with the small OSD. Then the screen will show as below.
The setting procedure is the same as above.
PATTERN SETUP
N TITLE SEC PERCENT
01 : P01 000 00.0
02 : P02 000 00.0
03 : P03 000 00.0
04 : P04 000 00.0
05 : P05 000 00.0
06 : P06 000 00.0
07 : P07 000 00.0
08 : P08 000 00.0
SAVE AND EXIT
PATTERN AREA SETUP
CTRL KEY
NUMBER 01
000 00.0%
0001 01.0%
EXIT
