Protective stands
Ø6.6 N°2
sp.2 100
86
sm.50x45° N°4
60 60
MODEL DESCRIPTION L (mm)
SE-P 150 Protective stand H= 273 mm 273
SE-P 300 Protective stand H= 420 mm 420
SE-P 450 Protective stand H= 567 mm 567
SE-P 600 Protective stand H = 714 mm 714
SE-P 750 Protective stand H = 861 mm 861
SE-P 800 Protective stand H = 969 mm 969
SE-P 900 Protective stand H = 1069 mm 1069
SE-P 1050 Protective stand H = 1155 mm 1155
SE-P 1200 Protective stand H = 1302 mm 1369
SE-P 1350 Protective stand H = 1449 mm 1449
SE-P 1500 Protective stand H = 1596 mm 1596
Test Piece
MODEL DESCRIPTION
TP-30 Test piece Ø 30 mm
